Description
AMS1117 DC-DC converter to 5V power supply module
Specifications
- Input : DC 6-12V ( input voltage must be higher than the output voltage by 1V or more)
- Output : 5.0V (+-0.05v error ), 800mA (current load must not exceed 800ma)
- Specially designed with two pin mounting holes
- Input and output using 2P single row pin for easy connection ;
- PCB board size : 2.5cm * 1.1cm
- With power indicator light ( red )
