Description
The ARDUINO® GIGA R1 Wi-Fi is a powerful and versatile development board designed for advanced IoT, robotics, and creative projects. Featuring a dual-core STM32H7 microcontroller, built-in Wi-Fi® and Bluetooth®, and expanded I/O capabilities, this board is perfect for high-performance applications. Whether you're developing smart devices, automation systems, or interactive installations, the GIGA R1 Wi-Fi offers seamless connectivity and enhanced processing power.
Why GIGA R1 Wi-Fi Matters:
- Dual Core Performance – Handle complex applications with real-time tasks and parallel processing
- Built-in WiFi & Bluetooth – Seamlessly connect to the cloud or other smart devices
- Expandable I/O & Camera Interface – Ideal for robotics, vision systems, or advanced control panels
- USB-A Host Support – Connect peripherals like keyboards, flash drives, or HID devices
- Plenty of Flash & RAM – Enough room for machine learning, graphics, or data-heavy applications
Specifications
| Board | Name | Arduino® GIGA R1 Wi-Fi |
| SKU | ABX00063 | |
| Microcontroller | STM32H747XI dual Cortex®-M7+M4 32bit low power Arm® MCU (datasheet) | |
| Radio Module | Murata 1DX dual Wi-Fi 802.11b/g/n 65 Mbps and Bluetooth® (datasheet) | |
| Secure Element | ATECC608A-MAHDA-T (datasheet) | |
| USB | USB-C® | Programming Port / HID |
| USB-A | Host (enable with PA_15) | |
| Pins | Digital I/O Pins | 76 |
| Analog input pins | 12 | |
| DAC | 2 (DAC0/DAC1) | |
| PWM pins | 12 | |
| Misc | VRT & OFF pin | |
| Communication | UART | Yes, 4x |
| I2C | Yes, 3x | |
| SPI | Yes, 2x | |
| CAN | Yes (Requires an external transceiver) | |
| Connectors | Camera | I2C + D54-D67 |
| Display | D1N, D0N, D1P, D0P, CKN, CKP + D68-D75 | |
| Audio Jack | DAC0, DAC1, A7 | |
| Power | Circuit operating voltage | 3.3V |
| Input voltage (VIN) | 6-24V | |
| DC Current per I/O Pin | 8 mA | |
| Clock Speed | Cortex® M7 | 480 MHz |
| Cortex® M4 | 240 MHz | |
| Memory | STM32H747XI | 2MB Flash, 1MB RAM |
| Dimensions | Width | 53 mm |
| Length | 101 mm | |
