SEEED STUDIO Grove - Single-Point Infrared Thermometer - MLX90614 DCC with 35° FOV

SEEED STUDIOSKU: 101020895

Price:
Sale priceN$515.42

Tax included

Stock:
In stock
Write a review
| Ask a question

Description

This infrared thermometer module has a single-point medical-grade infrared temperature sensor (MLX90641), which can detect the temperature of objects with an accuracy of ±0.2°C in the body temperature range. At room temperature, the surface temperature of the measured object can reach an accuracy of ±0.5°C in a wide range. The module can use the I2C protocol to obtain data from the camera. The field of view (FOV) of this sensor is 35°, the temperature measurement range is -70°C~380°C, and the working temperature is that the sensor's Ta value is between -40°~85°.

Features

  • Single-point medical-grade infrared temperature sensor (MLX90614)
  • Wide temperature measurement range (-70℃~380℃)
  • I2C Grove interface for easy communication with an MCU

Specification

Specification Details
FOV 35°
Measurement accuracy ±0.2°C(body temperature range) / ±0.5°C
Measuring range -70°C~380°C(object temperature)
Senser operating temperature Ta is between -40°~85°
Refresh Rate 0.5Hz ~ 64Hz
Interface I2C
Voltage 3.3V-5V
Current ~18mA
