Description
The Shelly EM Gen3 is a smart electrical energy meter designed to monitor and manage single-phase power consumption with high accuracy. Built on the enhanced Gen3 platform, it offers reliable real-time tracking of voltage, current, active/reactive power, frequency, and energy usage. All accessible via the Shelly Smart Control app or integrated smart home systems. Compact and DIN-rail mountable, the Shelly EM Gen3 helps homeowners and businesses gain insight into energy patterns, optimize usage, and reduce costs.
Key Features
- Real-Time Energy Monitoring: Tracks voltage, current, power, frequency, and total energy (kWh).
- Smart Connectivity: Wi-Fi support (2.4 GHz) enables remote monitoring and control via the Shelly app.
- DIN-Rail Installation: Neat, secure mounting in electrical panels or distribution boards.
- Automation & Alerts: Set thresholds and receive notifications for over-usage or adverse conditions.
- Compact & Reliable: Designed for continuous operation with stable performance.
- Smart Integrations: Works with Shelly ecosystem, MQTT, REST API, and home automation platforms.
Specifications
- Model: Shelly EM Gen3
- Phases: Single-phase
- Measured Metrics: Voltage, Current, Active/Reactive Power, Energy (kWh),
- Connectivity: Wi-Fi 802.11 b/g/n (2.4 GHz)
- Mounting: DIN rail TS35/7.5 or TS35/15
- Operating Voltage: 110–240 V AC
- Current Measurement: Via external CTs (current transformers)
- App Control: Shelly Smart Control & integrations
- Protection Class: IP20 (indoor)
- Operating Temp.: –20 °C to +55 °C
Applications
Ideal for home energy monitoring, appliance tracking, load analysis, and cost optimization in residential or light commercial environments. The Shelly EM Gen3 helps you visualize consumption trends and make smarter decisions about usage patterns.
