Description
The Picoo series of small PT cameras raises the bar on performance. After detecting an intrusion, it triggers sound and light alarms, and then instantly relays vital information on the intrusion to the mobile client, keeping you informed no matter where you are. It supports two-way talk, allowing you to communicate with people in front of the camera in real time. It also can record full-color videos and information of key events using Smart Dual Illuminators, effectively reducing light pollution.
Specifications
-
Image Sensor
1/2.7" CMOS
Max. Resolution
2304 (H) × 1296 (V)
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
Illumination Distance
Up to 30 m (98.43 ft) (IR);
Up to 30 m (98.43 ft) (Warm Light)Illuminator On/Off Control
Auto
Illuminator Number
2 (IR LED); 2 (Warm light)
Angle Adjustment
Pan: 0°–355°;
Tilt: 0°–90°Lens
Max. Aperture
F1.6
Field of View
H: 87°; V: 44°; D: 105°
Intelligence
Vehicle Detection
Yes
Human Detection
Yes
Video
Video Compression
H.265
Video Frame Rate
Main stream: 2304 × 1296@(1-25/30 fps)
sub stream: 640 × 360@(1-25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.Resolution
3M (2304 × 1296); nHD (640 × 360)
Video Bit Rate
H.265: 80 kbps–4096 kbps
Day/Night
Auto(ICR)/Color/B/W
WDR
DWDR
Motion Detection
Yes
Smart Illumination
Yes
Image Rotation
0°/180°
Audio
Built-in MIC
Yes, built-in Mic
Built-in Speaker
Yes, built-in speaker
Audio Compression
G.711a
Network
Network Port
RJ-45 (10/100 Base-T)
Wi-Fi
IEEE 802.11b/g/n/ax 2.412-2.472 GHz, 2.4 G
Storage
Micro SD card (up to 256 GB)
Management Software
DMSS
Mobile Client
iOS;Android
Certification
Certifications
CE
Power
Power Supply
12 VDC
Power Consumption
Basic: 1.56 W;
Max.: 4.56 W (H.265+warm light on)Environment
Operating Temperature
–20 °C to +50 °C (–4 °F to +122 °F)
Operating Humidity
≤95%
Structure
Casing Material
Plastic
Product Dimensions
116 mm × 138 mm × 139 mm (4.57" × 5.43" × 5.47") (L × W × H)
Net Weight
425 g (0.94 lb)
