Description
The Shelly i3 allows you to connect three inputs to the i3 and control other Shelly devices such as the Shelly 1 or perform actions on any other device through the Shelly API. This allows for remote control of the devices without your mobile phone or from your PC with multi action support.
Shelly i3 Open Source
- has an embedded webserver
- has been designed for installation in a limited space, such as wall mounts, electrical control panels, etc.
- can function as a standalone device, as an accessory to a home automation controller, or it may be used as another automation system's component.
For more information please see Shelly Website and Datasheet
Specifications
POWER |
|
Power supply AC | 110-230V ±10%, 50/60Hz |
Power supply DC | 24 – 60V |
SPECIAL FUNCTIONS |
|
Complex scenes control | Activate or deactivate synchronized actions of several Shelly devices |
Overload protection | No |
Power measurement | No |
Working without a neutral line | No |
FEATURES |
|
Channels | 3 Channel |
Operational temperature | 0°C to + 40 °C |
Device power consumption | < 1 W |
Intelligent On/Off | No |
Sunrise/Sunset | No |
Weekly Schedule | No |
UL Listed option | No |
CONNECTIVITY |
|
Wireless/WiFi Protocol | 802.11 b/g/n |
Radiofrequency | 2400 - 2484 MHz |
Radio signal power | 1mW |
Range | up to 50 m outdoors and up to 30 m indoors (depending on the building materials) |
DIMENSIONS |
|
Size | 40mm x 36mm x 10mm |
